The Sunny Day Delay is the latest revision of a classic Dr. Scientist pedal based on the famed PT2399 delay chip. This newest version now features a brand new tone control, mix knob and expression input all in a smaller form factor than previous versions. Offering classic, warm delay tones and ambient, modulated washes of repeats, the Sunny Day Delay can find a home on any pedalboard.
Features
All analog circuit and controls
Uniquely designed circuit
High quality analog signal path
Premium parts and components throughout
True Bypass with soft touch relay switching
Full control over wet/dry mix
Expression pedal control over Mix
Buffered Input and Output
Top mounted audio and power jacks
Designed and handmade in B.C., Canada
Knobs
Delay – Sets the delay time from nearly instant to just over a second
Repeats – Sets the number of repeats from 1 to oscillating
Tone – Adjust the frequency response of the repeats
Mix – Adjusts the balance between the input signal (Dry) and the effect (Wet) signal
Mod Depth – Increases the amount of warble in the repeats
Mod Rate – Sets the speed of the modulation
Volume – Controls the overall signal level
Mod/Osc Footswitch – Either turns the modulation on/off or can be held for maximum repeats
Bypass – Engage or disengage the effect
Operation
500kΩ/1kΩ
100mA @ 9VDC, 2.1mm centre negative plug
True Bypass with soft touch relay switching
Additional Specs
Mono input, Mono output, TRS Expression input
Exp Input: TRS cable, 10k-25k Ohms ideally
All analog controls
Dimensions: 70mm wide, 129mm long, 59mm tall (2.75” wide, 5.1” long, 2.3” tall)
Additional Information
| Brand | Dr. Scientist |
|---|
