Empress Effects - ZOIA

ZOIA is almost everything - it is an open canvas to paint your sonic ideas. FM synthesis, CV tools, MIDI tools, audio effects, interface options - all at your fingertips. ZOIA transforms the rigmarole of interfacing a studio full of music gear and condenses it into one handy little box, which you can then interface with your own studio full of music gear.

In short, ZOIA is an infinite trick pony whose utility is limited only by your imagination.

Details:

80+ Modules and Growing

ZOIA comes packed with a vast collection of modules to create just about anything you can dream up. With ZOIA the only limit is your imagination!

Create your own effects, synths, control devices, and more!

Oscillators, LFOs, filters, bit crushers, envelope followers - these are just a handful of the included modules that can be connected in almost any way imaginable. If you can dream it up, you can create it!

20+ Ready-Made Effects Modules

Pre-built effects modules such as reverbs, delays, chorus', flangers, overdrives and more.</li>

Up to 64 Patches

Create and save up to 64 patches that can be easily recalled during live performance.

Swap and Share Patches

Join the community of ZOIA users on patchstorage.com to tryout other users patches, or upload your own awesome creations to share with the world.

SD Card Included

Load and save patches to/from ZOIA. We're also continuously improving the firmware by adding new modules and features, and fixing bugs. Download the newest firmware from empresseffects.com and load onto the ZOIA with the included SD card.

OLED Display Screen for Easy Editing

View all of ZOIA's module and parameter information on the high resolution OLED display screen.

Dedicated MIDI Jacks

1/8" MIDI in/out jacks allow you to connect to a huge range of external devices. Control ZOIA with a MIDI keyboard, or use ZOIA as the brain of your entire setup. 1/8" to MIDI dongles included.

Control Port Connectivity

The Empress control port will accept expression pedals, control voltage (in and out), external tap switches, and MIDI as well. and MIDI 1/8" in/out jacks allow you to connect a huge range of external devices to control any or all of ZOIA's functions and parameters. 1/8" to MIDI dongles included.

Customizable Patch Recall System

- The on-board stompswitches can be used in either scrolling- or bank-style preset modes, for quick on-the-fly patch recall that suits your workflow.</li>

Built-In Help Function

- Almost like having a built-in manual, the dedicated help function will give you quick information at a glance about ZOIA's various modules and options.</li>

High-Quality Audio

- 48kHz sampling, with 24 bit conversion and 32 bit internal processing.

Low-Noise Signal Path

- Features extremely low noise operation with a signal-to-noise of >105dB

Specs:

Input Impedance >= 1MΩ

Output Impedance 100Ω

Frequency Response (-3dB) 10Hz – 23.4kHz

Total Harmonic Distortion 0.22%

Dynamic Range 105.5 dBA

Input Headroom (no pad) +0.5 dBu

Input Headroom (6dB pad) +5.7 dBu

Input Headroom (12dB pad) +10.8 dBu

Output Headroom +16.2dBu

Power Input Connector 2.1mm Barrel Connector

Power Input Voltage 9V DC (center negative) - not included

Required Current 300mA

Height (enclosure only) 1.75”

Height (including controls) 2.625”

Length 5.7”

Width 3.75”

Weight 1.5lbs

More Infos and Videos can be found her at empresseffects.com
